Raleigh Circa I8 2010 Technical specs and features
| Brand | Raleigh |
| Model | Circa I8 |
| First production | 2010 |
| Bike category | Commuter |
| Bike sub-category | Comfort Commuter |
| Bike Pricing | Check price Here ==> |
| Parts And Accessories | Raleigh Circa I8 Parts |
| Available Sizes | - 15 (inches) / 38.1 (cm) - 15 (inches) - 17 (inches) / 43.18 (cm) - 17 (inches) - 19 (inches) / 48.26 (cm) - 19 (inches) |
Wheels And Breaking System
| Bike front tire | 26 X 1.95 (inches) Kenda K-841A With K-shield |
| Bike rear tire | Not Available |
| Bike wheel size | 26 (inches) Wheels |
| Brakeset type | Tektro Levers Tektro V-brake Brakes |
| Hubs for disc brakes | Rear: Shimano Nexus 8 Speed Internal Front: Joytech Alloy QR |
| Rims manufacturer | 36-hole Weinmann XC-260 |
| Spoke nipples type | Not Available |
| Spoke wheel | 14ga. Stainless |
Frame and Body Specifications
| Frame materials | Atomic 13 Aluminum |
| Frame type | TIG-welded |
| Handlebar construction | Alloy Comfort Easy-Reach |
| Handlebar extender | Optional |
| Handlebar stem details | Alloy Quill |
| Headset size | 1 1/8 (inches) Threaded Threaded |
Gearing Specs
| Bicycle chain | KMC HG40 |
| Bottom bracket shell width | Not Available |
| Bottom bracket type | Sealed Cartridge |
| Crankset parts and sizes | 36 Teeth Forged Aluminum |
| Gear shift levers | Shimano SL-8S20 Revo |
| Rear gear set | 20 Teeth 8-speed Internal |
Raleigh Circa I8 Fork System Data
| Derailleur (Front) | Not Available |
| Derailleur (Rear) | Not Available |
| Fork material | Unicrown Crown Aluminum |
| Fork type | Raleigh |
Other Specs of Raleigh Circa I8
| Component group sets | Comfort Mix |
| Available colors | - Black |
| Weight | Not Available |
| Pedals details | Avenir Comfort Platform |
| Rear shock absorber | Not Available |
| Saddle seat | Avenir Deluxe Comfort |
| Seat post extension | 27.2 (millimeters) Diameter Alloy Micro Adjust Bootless Suspension |
Raleigh Circa I8 picture
Circa I8 bike comparison
Raleigh Circa I8 Fuji Kyoto Lady
Raleigh Circa I8 Fuji Absolute
Raleigh Circa I8 Cannondale Silk Adventure 400 Mixte
Raleigh Circa I8 Schwinn Sierra 700 GSX
Raleigh Circa I8 bike review
Raleigh produced the Circa I8 bike in 2010 and can be classified as a Commuter bicycle.
Circa I8 bike is available in many sizes such as 15 (inches), 17 (inches) and 19 (inches).
Raleigh Commuter Circa I8 can be found in one single color which is Black.
This bike is equiped with 26 x 1.95" Kenda K-841A with K-shield tires and Stainless spoke wheel while the rims are manufactured by Weinmann XC-260, 36-hole. Raleigh equiped this exact model with Tektro V-brake brakes, Tektro levers braking system and Front: Joytech Alloy QR, Rear: Shimano Nexus 8 speed Internal hubs.
To guarantee the comfiest ride Raleigh used Atomic 13 Aluminum material for the frame. Alloy Comfort Easy-Reach high strength material is used on the handlebar of this Circa I8 to ensure the perfect handling while the stems are made of Alloy Quill.
For the smoothest biking experience Forged aluminum, 36 teeth is used on this bicycle linked to KMC HG40 chain that is easily replaceable as stated by Raleigh, the whole system is connected to a high reliability Shimano SL-8S20 Revo gear shift levers.
