Eastern Bikes Atom Ace Of Spades 2004 Technical specs and features
| Brand | Eastern Bikes |
| Model | Atom Ace Of Spades |
| First production | 2004 |
| Bike category | Freestyle |
| Bike sub-category | Freestyle And Jumping |
| Bike Pricing | Check price Here ==> |
| Parts And Accessories | Eastern Bikes Atom Ace of Spades Parts |
| Available Sizes | - Pro |
Wheels And Breaking System
| Bike front tire | 20 X 1.95 (inches) |
| Bike rear tire | Not Available |
| Bike wheel size | 20 (inches) Wheels |
| Brakeset type | Promax Alloy Rear Levers Aluminum U-brake Rear Brakes |
| Hubs for disc brakes | Atom Series 14 (millimeters) Axle |
| Rims manufacturer | 48-hole Atom Series |
| Spoke nipples type | Brass Nipples |
| Spoke wheel | 14ga. Straight Gauge Stainless Steel |
Frame and Body Specifications
| Frame materials | 4130 chromoly c |
| Frame type | TIG-welded |
| Handlebar construction | Eastern 2-piece Chromoly |
| Handlebar extender | Not Available |
| Handlebar stem details | Atom Series |
| Headset size | 1 1/8 (inches) Threadless Steel Threadless |
Gearing Specs
| Bicycle chain | 1/2 X 1/8 (inches) KMC Z410 |
| Bottom bracket shell width | American |
| Bottom bracket type | Not Available |
| Crankset parts and sizes | 39 Teeth 3-piece Chromoly 175 (millimeters) |
| Gear shift levers | Not Available |
| Rear gear set | 1-speed |
Eastern Bikes Atom Ace of Spades Fork System Data
| Derailleur (Front) | Not Available |
| Derailleur (Rear) | Not Available |
| Fork material | Unicrown Crown Chromoly |
| Fork type | Eastern |
Other Specs of Eastern Bikes Atom Ace of Spades
| Component group sets | Not Available |
| Available colors | - Black - Navy |
| Weight | Not Available |
| Pedals details | Wellgo LU-313 |
| Rear shock absorber | Not Available |
| Saddle seat | Eastern 9 (millimeters) Rails |
| Seat post extension | Chromoly Micro-adjust |
Eastern Bikes Atom Ace of Spades picture
Atom Ace of Spades bike comparison
Eastern Bikes Atom Ace of Spades Mosh Brass 1 Star
Eastern Bikes Atom Ace of Spades Diamondback Venom
Eastern Bikes Atom Ace of Spades Hoffman Bikes Rhythm EL1
Eastern Bikes Atom Ace of Spades Diamondback Sherman
Eastern Bikes Atom Ace of Spades bike review
Eastern Bikes produced the Atom Ace of Spades bike in 2004 and can be classified as a Freestyle bicycle, this exact model costs in american market arround $399.99.
Eastern Bikes Freestyle Atom Ace of Spades can be found in a few colors, among these colors Black and Navy .
This bike is equiped with 20 x 1.95" tires and Stainless steel spoke wheel while the rims are manufactured by Atom Series, 48-hole. Eastern Bikes equiped this exact model with Aluminum U-brake rear brakes, Promax alloy rear levers braking system and Atom Series 14mm axle hubs.
To guarantee the comfiest ride Eastern Bikes used 4130 chromoly material for the frame. Eastern 2-piece chromoly high strength material is used on the handlebar of this Atom Ace of Spades to ensure the perfect handling while the stems are made of Atom Series.
For the smoothest biking experience 3-piece chromoly 175mm, 39 teeth is used on this bicycle linked to KMC Z410 chain that is easily replaceable as stated by Eastern Bikes.
