Raleigh C40 2002 Technical specs and features
Brand | Raleigh |
Model | C40 |
First production | 2002 |
Bike category | Hybrid |
Bike sub-category | Hybrid |
Bike Pricing | Check price Here ==> |
Parts And Accessories | Raleigh C40 Parts |
Available Sizes | - 15 (inches) / 38.1 (cm) - 15 (inches) - 17 (inches) / 43.18 (cm) - 17 (inches) - 19 (inches) / 48.26 (cm) - 19 (inches) - 21 (inches) / 53.34 (cm) - 21 (inches) - 23 (inches) / 58.42 (cm) - 23 (inches) - womens 16 (inches) - womens 19 (inches) |
Wheels And Breaking System
Bike front tire | 700 X 38c Kenda K-830 |
Bike rear tire | Not Available |
Bike wheel size | 700c Wheels |
Brakeset type | Tektro 385A Levers Tektro 836A Linear Pull Brakes |
Hubs for disc brakes | Q and R Joy Tech Aluminum |
Rims manufacturer | 36-hole Weinmann 519 |
Spoke nipples type | Brass Nipples |
Spoke wheel | 14ga. Straight Gauge Sha-Dar Stainless Steel |
Frame and Body Specifications
Frame materials | 6061 T6 Aluminum |
Frame type | TIG-welded |
Handlebar construction | 2 (inches) Rise Aluminum |
Handlebar extender | Optional |
Handlebar stem details | Adjustable Aluminum |
Headset size | 1 1/8 (inches) Steel |
Gearing Specs
Bicycle chain | 1/2 X 3/32 (inches) KMC Z-82 |
Bottom bracket shell width | 68 (millimeters) English |
Bottom bracket type | 122 (millimeters) Spindle Sealed Cartridge |
Crankset parts and sizes | 28/38/48 Teeth Shimano FC-C203 |
Gear shift levers | Shimano Tourney RevoShift |
Rear gear set | 11 - 34 Teeth 8-speed |
Raleigh C40 Fork System Data
Derailleur (Front) | Dual-pull and clamp-on 31.8 (millimeters) Shimano C202 |
Derailleur (Rear) | Shimano C201 Rapid-Rise |
Fork material | Single Triple-clamp Crown Aluminum |
Fork type | 2.0 (inches) Travel RST 791 CL |
Other Specs of Raleigh C40
Component group sets | Hybrid Mix |
Available colors | - Blue - Red |
Weight | Unspecified |
Pedals details | Platform Resin |
Rear shock absorber | Not Available |
Saddle seat | Velo Comfort |
Seat post extension | 27.2 (millimeters) Diameter Suspension Aluminum |
Raleigh C40 picture
C40 bike comparison

Raleigh C40 Fuji Sagres

Raleigh C40 Jamis Boca


Raleigh C40 Norco Olympia

Raleigh C40 Peugeot Urbano
Raleigh C40 bike review
Raleigh produced the C40 bike in 2002 and can be classified as a Hybrid bicycle, this exact model costs in american market arround $329.99.
C40 bike is available in many sizes such as 15 (inches), 17 (inches), 19 (inches), 21 (inches), 23 (inches), womens 16 (inches) and womens 19 (inches).
Raleigh Hybrid C40 can be found in a few colors, among these colors Blue and Red .
This bike is equiped with 700 x 38c Kenda K-830 tires and Sha-Dar stainless steel spoke wheel while the rims are manufactured by Weinmann 519, 36-hole. Raleigh equiped this exact model with Tektro 836A Linear Pull brakes, Tektro 385A levers braking system and Joy Tech aluminum, Q/R hubs.
To guarantee the comfiest ride Raleigh used 6061 T6 aluminum material for the frame. Aluminum, 2" rise high strength material is used on the handlebar of this C40 to ensure the perfect handling while the stems are made of Aluminum, adjustable.
For the smoothest biking experience Shimano FC-C203, 28/38/48 teeth is used on this bicycle linked to KMC Z-82 chain that is easily replaceable as stated by Raleigh, the whole system is connected to a high reliability Shimano Tourney RevoShift gear shift levers.
