KHS XC 104 2011 VS Raleigh M3000 1997 specs comparison
KHS XC 104
General Infos| Model | XC 104 |
| Manufacturer | KHS |
| Year of production | 2011 |
| Current price | Check price Here ==> |
| Color choice | -Team Red and White |
| Sizes | - Small - Medium - Large - Extra large |
| Sizes | - Small - Medium - Large - Extra large |
Wheels And Breaking System
| Bike front tire | 26 X 2.1 (inches) Kenda Klaw |
| Bike rear tire | Not Available |
| Bike wheel size | 26 (inches) Wheels |
| Brakeset type | Alloy Linear Pull LeversBengal MB606 Brakes |
| Hubs for disc brakes | Alloy |
| Rims manufacturer | Weinmann Taura 2000 |
| Spoke nipples type | Not Available |
| Spoke wheel | 14ga. |
Frame and Body Specs
| Frame materials | Alloy |
| Frame type | TIG-welded |
| Handlebar construction | Alloy |
| Handlebar extender | Optional |
| Handlebar stem details | Alloy |
| Headset size | 1 1/8 (inches) Cane Creek Ahead |
Gearing Specifications
| Bicycle chain | KMC Z99 |
| Bottom bracket shell width | Not Available |
| Bottom bracket type | TruVative Power Spline |
| Crankset parts and sizes | 22/32/42 TeethTruVativ Isoflow |
| Gear shift levers | Shimano Alivio Rapid Fire |
| Rear gear set | 11 - 34 Teeth9-speed |
KHS XC 104 Fork System Data
| Derailleur (Front) | Shimano Alivio |
| Derailleur (Rear) | Shimano Alivio |
| Fork material | Single |
| Fork type | 100 (millimeters) TravelSpinner 300LC |
Other Specs of KHS XC 104
| Component group sets | Shimano Alivio |
| Pedals details | Wellgo Alloy ATB |
| Rear shock absorber | 120 (millimeters) TravelRockShox Bar 1.1 Air |
| Saddle seat | KHS Sport Dual Density |
| Seat post extension | Alloy Micro Adjust |
Raleigh M3000
General Infos| Model | M3000 |
| Manufacturer | Raleigh |
| Year of production | 1997 |
| Current price | Check price Here ==> |
| Color choice | -Black and silver |
| Sizes | - 16 (inches)- 18 (inches)- 20 (inches) |
Wheels And Breaking System
| Bike front tire | 26 X 2.00 (inches) Multi-terrain |
| Bike rear tire | Not Available |
| Bike wheel size | 26 (inches) Wheels |
| Brakeset type | Aluminum LeversShimano Altus Brakes |
| Hubs for disc brakes | Aluminum Quick Release |
| Rims manufacturer | 36-holeWeinmann 519 |
| Spoke nipples type | Brass Nipples |
| Spoke wheel | 2.0 (millimeters) Straight GaugeSteel |
Frame and Body Specs
| Frame materials | Chromoly Main Triangle and hi-tensile Steel Rear Stays |
| Frame type | TIG-welded |
| Handlebar construction | Steel |
| Handlebar extender | Optional |
| Handlebar stem details | Steel |
| Headset size | 1 (inches) Steel |
Gearing Specifications
| Bicycle chain | 1/2 X 3/32 (inches)Shimano CN-UG50 |
| Bottom bracket shell width | 68 (millimeters) English |
| Bottom bracket type | 116 (millimeters) SpindleVictor VPB-33 |
| Crankset parts and sizes | 22/34/42 TeethTracer MA-4i |
| Gear shift levers | Grip Shift MRX-170 |
| Rear gear set | 14 - 28 Teeth7-speed |
Raleigh M3000 Fork System Data
| Derailleur (Front) | Top-pull and clamp-on 28.6 (millimeters)Shimano AceraX Top-swing |
| Derailleur (Rear) | Shimano AceraX |
| Fork material | Triple-clamp CrownAluminum |
| Fork type | SR DuoTrack 7007 |
Other Specs of Raleigh M3000
| Component group sets | Shimano AceraX |
| Pedals details | Resin |
| Rear shock absorber | 2.0 (inches) TravelRaleigh |
| Saddle seat | Sella Stratos HyperPlush |
| Seat post extension | 26.0 (millimeters) DiameterSteel Micro-adjust |
Related Bike comparison
KHS XC 104 Raleigh Ram TX2500
