VooDoo D-Jab XTR/Z-1 BAM 1999 Technical specs and features
| Brand | VooDoo |
| Model | D-Jab XTR/Z-1 BAM |
| First production | 1999 |
| Bike category | Mountain Bike |
| Bike sub-category | Mountain With Front Suspension |
| Bike Pricing | Check price Here ==> |
| Parts And Accessories | VooDoo D-Jab XTR/Z-1 BAM Parts |
| Available Sizes | - 14 (inches) / 35.56 (cm) - 14 (inches) - 16 (inches) / 40.64 (cm) - 16 (inches) - 17 (inches) / 43.18 (cm) - 17 (inches) - 18.5 (inches) / 46.99 (cm) - 18.5 (inches) - 19.5 (inches) / 49.53 (cm) - 19.5 (inches) - 21 (inches) / 53.34 (cm) - 21 (inches) |
Wheels And Breaking System
| Bike front tire | 26 X 2.10 (inches) WTB VelociRaptor 44/50 Kevlar |
| Bike rear tire | Not Available |
| Bike wheel size | 26 (inches) Wheels |
| Brakeset type | Shimano XTR Levers Shimano XTR V-Brake Brakes |
| Hubs for disc brakes | Shimano XTR |
| Rims manufacturer | 32-hole Mavic X517 |
| Spoke nipples type | Alloy Nipples |
| Spoke wheel | 2.0 (millimeters) Double-butted Wheelsmith Stainless Steel |
Frame and Body Specifications
| Frame materials | 3Al and 2.5V Titanium |
| Frame type | TIG-welded |
| Handlebar construction | Titec PG Titanium |
| Handlebar extender | Optional |
| Handlebar stem details | Titec AL-PG |
| Headset size | 1 1/8 (inches) Threadless WTB Grease Guard |
Gearing Specs
| Bicycle chain | 1/2 X 3/32 (inches) Shimano CN-7700 |
| Bottom bracket shell width | 68 (millimeters) English |
| Bottom bracket type | 110 (millimeters) Spindle Shimano BB-M952 |
| Crankset parts and sizes | 24/34/46 Teeth Shimano XTR M952 |
| Gear shift levers | Shimano XTR RapidFire SL |
| Rear gear set | 12 - 34 Teeth 9-speed |
VooDoo D-Jab XTR/Z-1 BAM Fork System Data
| Derailleur (Front) | Top-pull and clamp-on 28.6 (millimeters) Shimano XTR Top-swing |
| Derailleur (Rear) | Shimano XTR SGS |
| Fork material | Triple-clamp Crown Aluminum |
| Fork type | 5.0 (inches) Travel Marzocchi Bomber Z-1 BAM |
Other Specs of VooDoo D-Jab XTR/Z-1 BAM
| Component group sets | Shimano XTR |
| Available colors | - Natural Titanium |
| Weight | Unspecified |
| Pedals details | Shimano PD-M747 SPD |
| Rear shock absorber | Not Available |
| Saddle seat | Koski Titanium and vinyl and kevlar |
| Seat post extension | 27.2 (millimeters) Diameter Titec Aluminum |
VooDoo D-Jab XTR/Z-1 BAM picture
D-Jab XTR/Z-1 BAM bike comparison
VooDoo D-Jab XTR/Z-1 BAM Trek 930
VooDoo D-Jab XTR/Z-1 BAM Scott Contessa Scale
VooDoo D-Jab XTR/Z-1 BAM Litespeed Obed (01)
VooDoo D-Jab XTR/Z-1 BAM Iron Horse MT500
VooDoo D-Jab XTR/Z-1 BAM bike review
VooDoo produced the D-Jab XTR/Z-1 BAM bike in 1999 and can be classified as a Mountain bike bicycle, this exact model costs in american market arround $3,609.00.
D-Jab XTR/Z-1 BAM bike is available in many sizes such as 14 (inches), 16 (inches), 17 (inches), 18.5 (inches), 19.5 (inches) and 21 (inches).
VooDoo Mountain bike D-Jab XTR/Z-1 BAM can be found in a few colors, among these colors Natural Titanium .
This bike is equiped with 26 x 2.10" WTB VelociRaptor 44/50 kevlar tires and Wheelsmith stainless steel spoke wheel while the rims are manufactured by Mavic X517, 32-hole. VooDoo equiped this exact model with Shimano XTR V-Brake brakes, Shimano XTR levers braking system and Shimano XTR hubs.
To guarantee the comfiest ride VooDoo used 3Al/2.5V titanium material for the frame. Titec PG titanium high strength material is used on the handlebar of this D-Jab XTR/Z-1 BAM to ensure the perfect handling while the stems are made of Titec AL-PG.
For the smoothest biking experience Shimano XTR M952, 24/34/46 teeth is used on this bicycle linked to Shimano CN-7700 chain that is easily replaceable as stated by VooDoo, the whole system is connected to a high reliability Shimano XTR RapidFire SL gear shift levers.
