Raleigh M45 2000 VS Fuji MT. FUJI-SX 1998 specs comparison

Raleigh M45

General Infos

Model	M45
Manufacturer	Raleigh
Year of production	2000
Current price	Check price Here ==>
Color choice	-New Wave Blue
Sizes	- 14 (inches) - 16 (inches) - 18 (inches) - 20 (inches) - 22 (inches) - 24 (inches) - womens 16 (inches) - womens 19 (inches)
Sizes	- 14 (inches) - 16 (inches) - 18 (inches) - 20 (inches) - 22 (inches) - 24 (inches) - womens 16 (inches) - womens 19 (inches)

Wheels And Breaking System

Bike front tire	26 X 1.95 (inches) Kenda K-850
Bike rear tire	Not Available
Bike wheel size	26 (inches) Wheels
Brakeset type	Alloy Levers Aluminum Linear-pull Brakes
Hubs for disc brakes	Q and R Joy Tech Aluminum
Rims manufacturer	36-hole Alex X-101
Spoke nipples type	Brass Nipples
Spoke wheel	2.0 (millimeters) Straight Gauge Chung Nan Stainless Steel

Frame and Body Specs

Frame materials	7005 Aluminum With Replaceable Derailleur Hanger
Frame type	TIG-welded
Handlebar construction	Steel
Handlebar extender	Optional
Handlebar stem details	Steel
Headset size	1 1/8 (inches) Threadless Victor VP-H94

Gearing Specifications

Bicycle chain	1/2 X 3/32 (inches) KMC Z-51
Bottom bracket shell width	68 (millimeters) English
Bottom bracket type	120 (millimeters) Spindle Victor VPB-33
Crankset parts and sizes	28/38/48 Teeth Shimano Tourney TY-40
Gear shift levers	Shimano Revo
Rear gear set	14 - 28 Teeth 7-speed

Raleigh M45 Fork System Data

Derailleur (Front)	Top-pull and clamp-on 31.8 (millimeters) Suntour TP-16
Derailleur (Rear)	Shimano MR-40
Fork material	Aluminum and chromoly
Fork type	2.0 (inches) Travel SR M6200

Other Specs of Raleigh M45

Component group sets	Mountain Mix
Pedals details	MTB Nylon
Rear shock absorber	Not Available
Saddle seat	Selle Stratos Enhanced Comfort
Seat post extension	27.2 (millimeters) Diameter Aluminum Micro-adjust

Fuji Mt. Fuji-SX

General Infos

Model	Mt. Fuji-SX
Manufacturer	Fuji
Year of production	1998
Current price	Check price Here ==>
Color choice	-Yellow Jacket
Sizes	- 15 (inches) - 17 (inches) - 19 (inches) - 20.5 (inches) - 22 (inches)

Wheels And Breaking System

Bike front tire	Rear: 26 X 2.00 (inches) Ritchey Speed Max Omega Front: 26 X 2.00 (inches) Ritchey Speed Max Alpha
Bike rear tire	Not Available
Bike wheel size	26 (inches) Wheels
Brakeset type	Real Levers Shimano XTR V-Brake Brakes
Hubs for disc brakes	Mavic Crossmax
Rims manufacturer	26-hole and 28-hole Mavic Crossmax
Spoke nipples type	Alloy Nipples
Spoke wheel	1.8 (millimeters) Straight Pull Mavic Stainless Steel

Frame and Body Specs

Frame materials	Easton ProGram Elite Double-butted
Frame type	TIG-welded
Handlebar construction	Titec Titanium
Handlebar extender	Fuji Aluminum
Handlebar stem details	Syncros Hinge
Headset size	1 1/8 (inches) Threadless WTB Momentum Grease Guard

Gearing Specifications

Bicycle chain	1/2 X 3/32 (inches) Shimano CN-HG90
Bottom bracket shell width	68 (millimeters) English
Bottom bracket type	112.5 (millimeters) Spindle Shimano BB-M950
Crankset parts and sizes	24/34/46 Teeth Shimano XTR M950
Gear shift levers	Shimano XTR RapidFire SL
Rear gear set	11 - 30 Teeth 8-speed

Fuji Mt. Fuji-SX Fork System Data

Derailleur (Front)	Bottom-pull and clamp-on 35.0 (millimeters) Shimano XTR Top-swing
Derailleur (Rear)	Shimano XTR SGS
Fork material	Triple-clamp Crown Aluminum and magnesium
Fork type	Rock Shox Sid

Other Specs of Fuji Mt. Fuji-SX

Component group sets	Shimano XTR
Pedals details	Time ATAC Carbon
Rear shock absorber	Not Available
Saddle seat	Selle Italia Nitrox PD
Seat post extension	Syncros Hardcore Aluminum
