Raleigh PASSAGE 4.5 2007 VS Trek 750 1997 specs comparison
Raleigh Passage 4.5
General Infos| Model | Passage 4.5 |
| Manufacturer | Raleigh |
| Year of production | 2007 |
| Current price | Check price Here ==> |
| Color choice |
- Bright Teal -Pearl Black |
| Sizes |
- 15 (inches) - 17 (inches) - 19 (inches) - 21 (inches) - 23 (inches) - women's 16 (inches) - women's 19 (inches) |
| Sizes |
- 15 (inches) - 17 (inches) - 19 (inches) - 21 (inches) - 23 (inches) - women's 16 (inches) - women's 19 (inches) |
Wheels And Breaking System
| Bike front tire | 700 X 40c Kenda Cross With Kshield |
| Bike rear tire | Not Available |
| Bike wheel size | 700c Wheels |
| Brakeset type | Shimano EZ-Fire-50 Levers Tektro Alloy V-brake Brakes |
| Hubs for disc brakes | Rear: Shimano RM30 Front: Alloy QR |
| Rims manufacturer | 36-hole Weinmann XTB-26 |
| Spoke nipples type | Not Available |
| Spoke wheel | 14ga. Straight Gauge Stainless Steel |
Frame and Body Specs
| Frame materials | Atomic 13 Aluminum |
| Frame type | TIG-welded |
| Handlebar construction | Steel Riser |
| Handlebar extender | Optional |
| Handlebar stem details | Alloy Adjustable |
| Headset size | 1 1/8 (inches) Threadless Steel |
Gearing Specifications
| Bicycle chain | KMC Z82 |
| Bottom bracket shell width | Not Available |
| Bottom bracket type | Sealed Cartridge |
| Crankset parts and sizes | 28/38/48 Teeth Shimano TX-71 |
| Gear shift levers | Shimano EZ-Fire-50 |
| Rear gear set | 11 - 34 Teeth 8-speed |
Raleigh Passage 4.5 Fork System Data
| Derailleur (Front) | Shimano C50 |
| Derailleur (Rear) | Shimano Alivio |
| Fork material | Aluminum |
| Fork type | Raleigh |
Other Specs of Raleigh Passage 4.5
| Component group sets | Hybrid Mix |
| Pedals details | Comfort Platform |
| Rear shock absorber | Not Available |
| Saddle seat | Avenir Deluxe Comfort Gel Web Spring |
| Seat post extension | 27.2 (millimeters) Diameter Alloy Micro Adjust Suspension |
Trek 750
General Infos| Model | 750 |
| Manufacturer | Trek |
| Year of production | 1997 |
| Current price | Check price Here ==> |
| Color choice |
-Dark blue |
| Sizes |
- 15 (inches) - 17 (inches) - 19 (inches) - 21 (inches) - 23 (inches) - womens 17 (inches) - womens 20 (inches) |
Wheels And Breaking System
| Bike front tire | 700 X 38c Trek Invert II |
| Bike rear tire | Not Available |
| Bike wheel size | 700c Wheels |
| Brakeset type | Tektro RBP-376A Levers Shimano Alivio M-System Brakes |
| Hubs for disc brakes | Rear: Shimano R050 Silent Clutch Front: Shimano Alivio |
| Rims manufacturer | 32-hole Matrix Vapor |
| Spoke nipples type | Brass Nipples |
| Spoke wheel | 2.0 (millimeters) Straight Gauge DT Stainless Steel |
Frame and Body Specs
| Frame materials | Double-butted Chromoly |
| Frame type | TIG-welded |
| Handlebar construction | System 1 |
| Handlebar extender | Optional |
| Handlebar stem details | System 1 |
| Headset size | 1 (inches) Tange-Seiki Passage |
Gearing Specifications
| Bicycle chain | 1/2 X 3/32 (inches) Shimano CN-IG31 |
| Bottom bracket shell width | 68 (millimeters) English |
| Bottom bracket type | 110 (millimeters) Spindle Shimano BB-LP26 |
| Crankset parts and sizes | 22/32/42 Teeth Shimano STX |
| Gear shift levers | Grip Shift SRT-400i |
| Rear gear set | 11 - 28 Teeth 7-speed |
Trek 750 Fork System Data
| Derailleur (Front) | Top-pull and clamp-on 31.8 (millimeters) Shimano STX |
| Derailleur (Rear) | Shimano STX |
| Fork material | Unicrown Crown Chromoly |
| Fork type | Trek |
Other Specs of Trek 750
| Component group sets | Shimano STX and Alivio |
| Pedals details | System 1 With Clips & Straps |
| Rear shock absorber | Not Available |
| Saddle seat | Not Available |
| Seat post extension | 27.2 (millimeters) Diameter Aluminum Micro-adjust |
