Redline RAID 2003 VS Haro BACKTRAIL X3 2005 specs comparison
Redline Raid
General Infos| Model | Raid |
| Manufacturer | Redline |
| Year of production | 2003 |
| Current price | Check price Here ==> |
| Color choice |
- Chrome -Blue and Flames |
| Sizes |
- Junior |
| Sizes |
- Junior |
Wheels And Breaking System
| Bike front tire | Rear: 20 X 1.75 (inches) Redline Logo Front: 20 X 2.00 (inches) Redline Logo |
| Bike rear tire | Not Available |
| Bike wheel size | 20 (inches) Wheels |
| Brakeset type | Promax Alloy Rear Levers ProMax Linear-pull Rear Brakes |
| Hubs for disc brakes | Steel |
| Rims manufacturer | 36-hole Alex Y-2000 |
| Spoke nipples type | Brass Nipples |
| Spoke wheel | 14ga. Straight Gauge |
Frame and Body Specs
| Frame materials | Hi-tensile Steel |
| Frame type | Pulse-welded |
| Handlebar construction | Redline Junior Bars |
| Handlebar extender | Optional |
| Handlebar stem details | Aluminum 4 Bolt |
| Headset size | 1 1/8 (inches) Threaded Steel |
Gearing Specifications
| Bicycle chain | 1/2 X 3/32 (inches) KMC Z410 |
| Bottom bracket shell width | Not Available |
| Bottom bracket type | Loose Ball |
| Crankset parts and sizes | 40 Teeth 1-piece 5 1/2 (inches) |
| Gear shift levers | Not Available |
| Rear gear set | 16 Teeth 1-speed |
Redline Raid Fork System Data
| Derailleur (Front) | Not Available |
| Derailleur (Rear) | Not Available |
| Fork material | Unicrown Crown Hi-tensile Steel |
| Fork type | Redline |
Other Specs of Redline Raid
| Component group sets | Not Available |
| Pedals details | Redline Aluminum |
| Rear shock absorber | Not Available |
| Saddle seat | Redline |
| Seat post extension | Steel Micro-adjust |
Haro Backtrail X3
General Infos| Model | Backtrail X3 |
| Manufacturer | Haro |
| Year of production | 2005 |
| Current price | Check price Here ==> |
| Color choice |
-Not found |
| Sizes |
- Not available |
Wheels And Breaking System
| Bike front tire | Rear: 20 X 2.10 (inches) Haro Catapult Front: 20 X 2.25 (inches) Haro Catapult |
| Bike rear tire | Not Available |
| Bike wheel size | 20 (inches) Wheels |
| Brakeset type | Tektro Alloy Reach Adjust Rear Levers Tektro U-brake Rear Brakes |
| Hubs for disc brakes | Rear: Haro Aluminum Cassette Front: Haro Aluminum |
| Rims manufacturer | 48-hole Haro Aluminum |
| Spoke nipples type | Brass Nipples |
| Spoke wheel | 14ga. Straight Gauge |
Frame and Body Specs
| Frame materials | 3-tube Chromoly |
| Frame type | TIG-welded |
| Handlebar construction | Haro Street |
| Handlebar extender | Not Available |
| Handlebar stem details | Haro Clamp-On |
| Headset size | 1 1/8 (inches) Threadless TH Power Pro |
Gearing Specifications
| Bicycle chain | 1/2 X 1/8 (inches) KMC Z410 |
| Bottom bracket shell width | Not Available |
| Bottom bracket type | Sealed |
| Crankset parts and sizes | 36 Teeth Haro Tubular CrMo 3-Piece |
| Gear shift levers | Not Available |
| Rear gear set | 13 Teeth 1-speed |
Haro Backtrail X3 Fork System Data
| Derailleur (Front) | Not Available |
| Derailleur (Rear) | Not Available |
| Fork material | Unicrown Crown Chromoly |
| Fork type | Haro |
Other Specs of Haro Backtrail X3
| Component group sets | Not Available |
| Pedals details | Haro DX Alloy |
| Rear shock absorber | Not Available |
| Saddle seat | Haro Padded |
| Seat post extension | 25.4 (millimeters) Diameter Haro Aluminum Micro-adjust |
