Marin Stelvio 2005 Technical specs and features

Brand Marin
Model Stelvio
First production 2005
Bike category Road
Bike sub-category Road Race & Triathlon
Bike Pricing Check price Here ==>
Parts And Accessories Marin Stelvio Parts
Available Sizes - Small
- medium
- large
- xlarge
- xxlarge


Wheels And Breaking System

Bike front tire700 X 23c Vittoria Diamante Pro
Bike rear tireNot Available
Bike wheel size700c Wheels
Brakeset type Campagnolo Chorus Ergo Levers
Campagnolo Chorus Dual Pivot Brakes
Hubs for disc brakesFSA RD-600
Rims manufacturerFSA RD-600
Spoke nipples typeNot Available
Spoke wheelNot Available

Frame and Body Specifications

Frame materialsCXR Venus 7 Carbon
Frame typeTIG-welded
Handlebar constructionFSA K-Wing Aero
Handlebar extenderOptional
Handlebar stem detailsFSA OS-115
Headset size1 1/8 (inches) Integrated Campagnolo Chorus

Gearing Specs

Bicycle chain 1/2 X 3/32 (inches)
Campagnolo Record
Bottom bracket shell widthNot Available
Bottom bracket typeFSA Mega Exo
Crankset parts and sizes 39/53 Teeth
FSA K-Force Mega Exo
Gear shift leversCampagnolo Chorus Ergo
Rear gear set 11 - 23 Teeth
10-speed

Marin Stelvio Fork System Data

Derailleur (Front)Campagnolo Chorus
Derailleur (Rear)Campagnolo Record
Fork material Aero Crown
Carbon Fiber
Fork typeTrigon Carbon Monocoque

Other Specs of Marin Stelvio

Component group setsRoad Mix
Available colors - Carbon Gloss Black
Weight Unspecified
Pedals detailsOptional
Rear shock absorberNot Available
Saddle seatSelle Italia SLR XP
Seat post extension 27.2 (millimeters) Diameter
FSA SL-K


Marin Stelvio bike review

Marin produced the Stelvio bike in 2005 and can be classified as a Road bicycle.
Stelvio bike is available in many sizes such as Small , medium , large , xlarge and xxlarge .
Marin Road Stelvio can be found in a few colors, among these colors Carbon Gloss Black .
This bike is equiped with 700 x 23c Vittoria Diamante Pro tires while the rims are manufactured by FSA RD-600. Marin equiped this exact model with Campagnolo Chorus dual pivot brakes, Campagnolo Chorus Ergo levers braking system and FSA RD-600 hubs.
To guarantee the comfiest ride Marin used CXR Venus 7 Carbon material for the frame. FSA K-Wing Aero high strength material is used on the handlebar of this Stelvio to ensure the perfect handling while the stems are made of FSA OS-115.
For the smoothest biking experience FSA K-Force Mega Exo, 39/53 teeth is used on this bicycle linked to Campagnolo Record chain that is easily replaceable as stated by Marin, the whole system is connected to a high reliability Campagnolo Chorus Ergo gear shift levers.
