Marin Stelvio 2005 Technical specs and features
| Brand | Marin |
| Model | Stelvio |
| First production | 2005 |
| Bike category | Road |
| Bike sub-category | Road Race & Triathlon |
| Bike Pricing | See price on Amazon |
| Parts And Accessories | Marin Stelvio Parts |
| Available Sizes | - Small - medium - large - xlarge - xxlarge |
Wheels And Breaking System
| Bike front tire | 700 X 23c Vittoria Diamante Pro |
| Bike rear tire | Not Available |
| Bike wheel size | 700c Wheels |
| Brakeset type | Campagnolo Chorus Ergo LeversCampagnolo Chorus Dual Pivot Brakes |
| Hubs for disc brakes | FSA RD-600 |
| Rims manufacturer | FSA RD-600 |
| Spoke nipples type | Not Available |
| Spoke wheel | Not Available |
Frame and Body Specifications
| Frame materials | CXR Venus 7 Carbon |
| Frame type | TIG-welded |
| Handlebar construction | FSA K-Wing Aero |
| Handlebar extender | Optional |
| Handlebar stem details | FSA OS-115 |
| Headset size | 1 1/8 (inches) Integrated Campagnolo Chorus |
Gearing Specs
| Bicycle chain | 1/2 X 3/32 (inches)Campagnolo Record |
| Bottom bracket shell width | Not Available |
| Bottom bracket type | FSA Mega Exo |
| Crankset parts and sizes | 39/53 TeethFSA K-Force Mega Exo |
| Gear shift levers | Campagnolo Chorus Ergo |
| Rear gear set | 11 - 23 Teeth10-speed |
Marin Stelvio Fork System Data
| Derailleur (Front) | Campagnolo Chorus |
| Derailleur (Rear) | Campagnolo Record |
| Fork material | Aero CrownCarbon Fiber |
| Fork type | Trigon Carbon Monocoque |
Other Specs of Marin Stelvio
| Component group sets | Road Mix |
| Available colors | - Carbon Gloss Black |
| Weight | Unspecified |
| Pedals details | Optional |
| Rear shock absorber | Not Available |
| Saddle seat | Selle Italia SLR XP |
| Seat post extension | 27.2 (millimeters) DiameterFSA SL-K |
Marin Stelvio picture
Stelvio bike comparison
Marin Stelvio
Specialized M2 Road Comp
Marin Stelvio
Macalu Titanium Racing (Excel)
Marin Stelvio
De Rosa SLX Professional
Marin Stelvio
Giant Cadex CFR-3
Marin Stelvio Specialized M2 Road Comp
Marin Stelvio Macalu Titanium Racing (Excel)
Marin Stelvio De Rosa SLX Professional
Marin Stelvio Giant Cadex CFR-3
Marin Stelvio bike review
Marin produced the Stelvio bike in 2005 and can be classified as a Road bicycle.Stelvio bike is available in many sizes such as Small , medium , large , xlarge and xxlarge .
Marin Road Stelvio can be found in a few colors, among these colors Carbon Gloss Black .
This bike is equiped with 700 x 23c Vittoria Diamante Pro tires while the rims are manufactured by FSA RD-600. Marin equiped this exact model with Campagnolo Chorus dual pivot brakes, Campagnolo Chorus Ergo levers braking system and FSA RD-600 hubs.
To guarantee the comfiest ride Marin used CXR Venus 7 Carbon material for the frame. FSA K-Wing Aero high strength material is used on the handlebar of this Stelvio to ensure the perfect handling while the stems are made of FSA OS-115.
For the smoothest biking experience FSA K-Force Mega Exo, 39/53 teeth is used on this bicycle linked to Campagnolo Record chain that is easily replaceable as stated by Marin, the whole system is connected to a high reliability Campagnolo Chorus Ergo gear shift levers.
