TNT M-80 1996 VS Redline RL 1.2 2009 specs comparison
TNT M-80
General Infos| Model | M-80 |
| Manufacturer | TNT |
| Year of production | 1996 |
| Current price | Check price Here ==> |
| Color choice |
- chrome-plated - dark blue - gray - green - white - yellow -Black |
| Sizes |
- Boys |
| Sizes |
- Boys |
Wheels And Breaking System
| Bike front tire | 20 X 1.75 (inches) VRB Comp III Type |
| Bike rear tire | Not Available |
| Bike wheel size | 20 (inches) Wheels |
| Brakeset type | Dia-Compe Tech 4 Levers Shimano Cantilever Alloy Brakes |
| Hubs for disc brakes | Not Available |
| Rims manufacturer | 36-hole Weinmann |
| Spoke nipples type | Brass Nipples |
| Spoke wheel | Straight Gauge Stainless Steel |
Frame and Body Specs
| Frame materials | True Temper Chromoly |
| Frame type | TIG-welded Steel |
| Handlebar construction | BMX Steel |
| Handlebar extender | Not Available |
| Handlebar stem details | TNT |
| Headset size | 1 (inches) YST Steel |
Gearing Specifications
| Bicycle chain | 1/2 X 1/8 (inches) KMC 410 |
| Bottom bracket shell width | 68 (millimeters) Threadless |
| Bottom bracket type | YST |
| Crankset parts and sizes | 44 Teeth 1-piece Chromoly 7 (inches) |
| Gear shift levers | Not Available |
| Rear gear set | 16 Teeth 1-speed |
TNT M-80 Fork System Data
| Derailleur (Front) | Not Available |
| Derailleur (Rear) | Not Available |
| Fork material | True Temper Chromoly |
| Fork type | TNT Pro |
Other Specs of TNT M-80
| Component group sets | Not Available |
| Pedals details | Turbo Trap |
| Rear shock absorber | Not Available |
| Saddle seat | Viscount Dominator |
| Seat post extension | 22.2 (millimeters) Diameter TNT Steel |
Redline RL 1.2
General Infos| Model | RL 1.2 |
| Manufacturer | Redline |
| Year of production | 2009 |
| Current price | Check price Here ==> |
| Color choice |
- White -Red |
| Sizes |
- Not available |
Wheels And Breaking System
| Bike front tire | 20 X 1.95 (inches) Redline Freaky-X |
| Bike rear tire | Not Available |
| Bike wheel size | 20 (inches) Wheels |
| Brakeset type | Tektro 299A Rear Levers Tektro FX-340 U-brake Rear Brakes |
| Hubs for disc brakes | Rear: Redline Aluminum Flip-Flop 14 (millimeters) Front: Redline Aluminum 14 (millimeters) |
| Rims manufacturer | 48-hole Alex Y-303 |
| Spoke nipples type | Not Available |
| Spoke wheel | Not Available |
Frame and Body Specs
| Frame materials | Chromoly Seat Tube and hi-ten Steel |
| Frame type | TIG-welded |
| Handlebar construction | Redline Hi-Ten |
| Handlebar extender | Optional |
| Handlebar stem details | Redline Proline |
| Headset size | VP Threadless |
Gearing Specifications
| Bicycle chain | 1/2 X 1/8 (inches) KMC Z410 |
| Bottom bracket shell width | Not Available |
| Bottom bracket type | Mid BB |
| Crankset parts and sizes | 36 Teeth Redline Tubular Chromo |
| Gear shift levers | Not Available |
| Rear gear set | 13 Teeth 1-speed |
Redline RL 1.2 Fork System Data
| Derailleur (Front) | Not Available |
| Derailleur (Rear) | Not Available |
| Fork material | Unicrown Crown Chromoly and Hi-ten |
| Fork type | Redline Monster |
Other Specs of Redline RL 1.2
| Component group sets | BMX |
| Pedals details | Redline Aluminum |
| Rear shock absorber | Not Available |
| Saddle seat | Redline Park Bench |
| Seat post extension | 25.4 (millimeters) Diameter Redline |
